This page when placed at the left of page 2 (after printing) will give you a chart of specifications for various gas tubes. New models begin on page 3 which combines with page 4 in the same fashion.
TII GAS TUBE DATA
Page 1 of 4
Model
Number		 Figure
Number		 DC
Breakdown
Voltage		 Singel
Impulse
Discharge
Current		 AC
Discharge
Current
11 Cycles		 Impulse Breakdown Holdover
Voltage
at 200mA		 Imulse Life
500A at
10/100		 Cont.
Pg. 2-A
Voltage Waveform
v/µsec
11A 1 150-300 20 kA
10 kA / side		 130 A
65 A / side		 < 0.8 kV 10 kV NA 400 times
500 A / side		 Cont.
Pg. 2-B
11 B * # 1 300-500 20 kA
10 kA / side		 130 A
65 A / side		 < 1 kV 10 kV 150 v 400 times
500 A / side		 Cont.
Pg. 2-C
11 C 1 500-900 20 kA
10 kA / side		 130 A
65 A / side		 < 1.5 kV 10 kV 150 v 400 times
500 A / side		 Cont.
Pg. 2-D
31 A 2 150-300 40 kA
20 kA / side		 400 A
200 A / side		 < 0.8 kV 10 kV NA 1000 times
500 A / side		 Cont.
Pg. 2-E
31 B * # 2 300-500 40 kA
20 kA / side		 400 A
200 A / side		 < 1 kV 10 kV 150 v 1000 times
500 A / side		 Cont.
Pg. 2-F
31 C 2 500-900 40 kA
20 kA / side		 400 A
200 A / side		 < 1.5 kV 10 kV 150 v 1000 times
500 A / side		 Cont.
Pg. 2-G
24
(8 mm) !		 N/A 180-300 20 kA 65 A < 0.8 kV 10 kV 150 v 400 times Cont.
Pg. 2-H
25
(5mm)		 N/A 180-300 . . 0.6 kV
0.65 kV		 1 kV
10 kV		 . 5kA at 8/20 µS.
10 Applications		 Cont.
Pg. 2-I
26
(6mm)		 N/A 180-399 . . 0.6 kV
0.65 kV		 1 kV
10 kV		 . 5kA at 8/20 µS.
10 Applications		 Cont.
Pg. 2-J
44 # 6 300-500 10 kA 65 A 0.6 kV 100 V 150 v 400 times Cont.
Pg. 2-K
47 BT * 7 300-500 . . 0.75 kV 100 V 180 v 400 times Cont.
Pg. 2-L
44-090 6 Avg. 90 (Available 1st. Qtr. 1996) Cont.
Pg. 2-M
71 * # 8 300-500 20 kA
10 kA / side		 130 A
65 A / side		 < 1.0 kV 10 kV 150 v 400 times
500 A./ Side		 Cont.
Pg. 2-N
72 9 ELECTRICAL CHARACTERISTICS IDENTICAL TO TII 71 TUBE Cont.
Pg. 2-O
* = UL Recognized
# = REA Listed
! = CCITT		 NOTES:
- Insulation resistance of all gas tubes at 100 vDC = 1000 Megohms or more.
- While all TII gas tubes far exceed the characteristics shown in the above table, it is the policy of TII to
depict the characteristics as limited by various industry specifications (ie. Bellcore, REA, ect.).		 Cont.
Pg. 2-P
