TII Gas Tubes
75 SERIES - 3-ELECTRODE HEAVY DUTY
| Model Number |
75 |
| DC Breakdown Voltage |
375-475 |
| Single Impulse Discharge Current |
20 kA, 10 kA/Side |
| AC Discharge Current 11 Cycles |
N/A |
| Impulse Breakdown Voltage |
0.65kV, 0.75 kV |
| Impulse Breakdown Waveform v/µsec |
100 V, 10 kV |
| Holdover Voltage @200mA |
150 V |
| Impulse Life 500A @10/1000 |
400 times, 500/Side |
| Capacitance |
2 pF, (10 pF 2 F/S) |
| DC Arc Voltage |
30 V |
| Glow to Arc Transition Current |
1 A |
