Customer Bridge Module with
Auto-Jack RJ-11

TII 95 CBM




FEATURES
bulletTII Meets Bellcore GR49 Core
bulletUL 1863 Listed
bulletMost Reliable RJ-11 Performance In The Industry
bulletExceeds Bellcore Severe, Lightning Surge Requirements
bulletEliminates Need For RJ-11 Plug Maintenance
bulletOptional 1/2 Ringer, MTU, Radio Frequency Interference Fifter Equipped Or Overcurrent Protection
bulletRetro-Fits Many Installed N IDís

DESCRIPTION

The TII 95 Customer Bridge Module (CBM) is constructed of superior materials capable of withstanding harsh indoor and outdoor environments, such as UV degradation, chemical exposure, cold temperatures, and moisture even in severe cases.

TIIís 95 CBM includes such innovative features as environmentally protected internal connections, keeping moisture and contaminants out of the RJ-11 test port resulting in unsurpassed performance not found until now.

TIIís superior performing Customer Bridge Module includes TIIís unique (patent pending) Auto-JackTM RJ-11 which is totally protected from the environment, and requires no RJ-11 plug. This unit exceeds Bellcore requirements for severe climatic conditions, both first and second level lightning surge requirements in the open and short circuit mode, resulting in unparalleled reliability.

Customer terminations utilize insulated hex/slotted screws for termination. Each Customer Bridge Module is capable of accepting the standard RJ-11 plug for customer troubleshooting.

TIIís 95 Customer Bridge Modules can be retrofitted into Siecorís 8600 and Keptelís 4600/4600XL Network Interface Devices. This makes it possible to field upgrade most standard service line modules already installed.

Standard features such as customer locking/telco bypass, and fully hinged covers are all part of TIIís Customer Bridge Module. The modular design will also accommodate 1/2 Ringers, MTUís and RFI Filters.





ORDERING INFORMATION



BASE MODEL NO. 95



Options



X



XX



Customer Termination

Electronics



Insulated Screws

1

None

00



IDC Terminations

2

1/2 Ringer

01



(Rockers)




MTU

02




RFI Filter

08




Overcurrent Protection Level 1

09

Level I - units with PTCís
(Positive Temperature Coefficient)



Overcurrent Protection Level 2

10

Level 2 - units with PTCís & Inductors (Positive Temperature Coefficient)
