Polyphaser Drop-In Tower Strobe Flasher Protector
APPLICATION:
To prevent lightning energy from damaging strobe flasher and entering building power lines.
| Single or double strobe flasher models
| In-line protector for ac, HV, HV return, trigger and interlock
| Housed use only - fits inside some control boxes
| | |
Hook-up |
Surge:* |
Turn-on: |
Usage |
AC |
15kA |
200Vdc |
120Vac @ 15A |
HV & Return |
6.5kA |
2000Vdc |
2000Vdc |
Trigger & Return |
10kA |
400Vdc |
350Vdc |
interlock |
15kA |
200Vdc |
120Vac |
*IEC 1000-4-5 8/20µ waveform
Temperature: -40oC to +85oC Storage/Operating
ORDER INFORMATION:
IS-7WFU for single (7 wire) flasher unit
IS- I2WFU for dual (12 wire) flasher unit
