TII GAS TUBE DATA
Page 4 of 4 |
|
From
Pg. 3-A
|
Capacitance |
DC Arc
Voltage
Max. |
Glow to Acr
Transition
Current |
Transition
Time |
Listings and Approvals |
Notes |
From
Pg. 3-B |
2 pF |
30 V |
1 A |
. |
. |
. |
From
Pg. 3-C |
2 pF
(10 pF w/ F/S) |
30 V |
1 A |
. |
. |
FAIL
SAFE
AND
VENT SAFE
CLIPS
AVAILABLE
FOR THESE
TUBES.
SEE
FIG. 31 |
From
Pg. 3-D |
THIS TUBE NOT EQUIPPED WITH LEADS.
SEE MODEL. 73/74 NUMBERING MARTIX FOR ODERING INFORMATION |
From
Pg. 3-E |
2 pF
(10 pF w/ F/S) |
30 V |
1 A |
. |
. |
From
Pg. 3-F |
THIS TUBE NOT EQUIPPED WITH LEADS.
SEE MODEL. 73/74 NUMBERING MARTIX FOR ODERING INFORMATION |
From
Pg. 3-G |
2 pF
(10 pF w/ F/S) |
30 V |
1 A |
. |
. |
From
Pg. 3-H |
THIS TUBE NOT EQUIPPED WITH LEADS.
SEE MODEL. 73/74 NUMBERING MARTIX FOR ODERING INFORMATION |
From
Pg. 3-I |
2 pF
(10 pF w/ F/S) |
30 V |
1 A |
. |
. |
. |
From
Pg. 3-J |
2 pF |
30 V |
1 A |
0.5 µ/S. |
. |
. |
From
Pg. 3-K |
2 pF |
30 V |
1 A |
. |
. |
. |
From
Pg. 3-L |
THIS TUBE IS EQUIPPED WITH LEADS |
. |
From
Pg. 3-M |
2 pF
1 pF |
30 V
25 V |
1 A |
. |
. |
. |
From
Pg. 3-N |
THIS TUBE IS EQUIPPED WITH LEADS |
. |
From
Pg. 3-O |
2 pF |
30 V |
. |
. |
. |
. |
From
Pg. 3-P
|
NOTES (con't):
- Customers wishing a TII gas tube tested to "End of Life" for a specific requirement should contact COMM-OMNI.
- COMM-OMNI can provide other DC breakdown voltages for all gas tubes listed. |
